BE 11kVA Petrol Generator - Deluxe, House Electric Start | G11000-RELT Max

The G11000-RELT Max is a petrol generator rated at 11kVA.

Manufacturer specifications

BE Deluxe House Series Generator

• Our Powerease Deluxe line of generators is a powerful & reliable choice for the mains failure house backup! This compact unit is the ideal mid-size generator. Featuring electric key start, IP66 weatherproof outlets, large muffler for quiet running compared to standard generators.
• The G11000-RELT MAX is not fitted with a M.E.N Link or RCD - This is designed for direct connection to a house/building for mains failure applications. Connection to a house/building must still be undertaken and set up by a qualified electrical contractor.
• It is recommended the electrical contractor installs a single phase 32A receptacle at the location of power intake to the building along with a manual changeover switch or Automatic Transfer Switch for fully automated mains failure usage.

Frame

• Compact Deluxe Generator
• Black Powder Coated Heavy Duty Roll Frame
• Heavy Duty Anti-Vibration Mounts
• House Ready Control Panel
• Digital V.F.T
• ATS Ready - Part # RAT 35607-YCK0110
• LED Work Light on Control Panel
• Weight 98 kg
• Dimensions: L 740 x W 576 x H 577 mm (w/o Wheels)

Engine

• Powerease 4 Stroke, 17 hp Petrol Engine
• Long Range 28 L Fuel Tank
• Electric/Recoil Start
• Low Oil Shutdown
• Safety Shut-Off Switch

Performance

• 240 V AC Clean Power
• 8000W Running / 8500W Max Power / 11.0kVA Power & Watts
• AVR (Automatic Voltage Regulator) Keeps Consistent Clean Power
• 6+ Hour Run Time @ 100% Load
• 1 x 15A, 1 x 32A IP66 Weatherproof Outlets
• Single MCB (Mini Circuit Breaker)

Manuals and documents

• Owner's manual (PDF)
• Parts diagram (PDF)
• Parts diagram (2) (PDF)
• Parts diagram (3) (PDF)
