Description
The HW3524HG12V is a hot water petrol pressure washer rated at 3,500 PSI and 21 litres a minute. Power comes from a Honda GX690 V Twin 24 hp engine.
Manufacturer specifications
Truck/Trailer Mount Hot Water Pressure
Pressure Washer - Hot 3,500 PSI @ 21 L/min with 12V Burner
Pump
- Preset brass external unloader valve
- Forged brass manifold
- Thermal relief valve
- Low pressure detergent ingector
- Belt Drive 1,750 RPM
Engine
- Honda GX690
- 12V Electric start, 80A deep cycle battery included
Frame:
- Heavy-Duty 1.5" outside diameter
- Reinforced powder coated steel tube frame with center balanced lift
Components
- No.1 or No.2 diesel or kerosene fired burner
- 12V Beckett burner with low voltage inhibitor
- Stainless steel coil wrap
- 1/2" Heavy duty schedule 80 carbon steel cold rolled pipe @ 5500psi
- Adjustable thermostat up to 93°c /200°F with illuminated rocker switch
- Hour meter
- 12" Engine and pump oil drain hoses
Unit Includes
- Quick connect nozzles - 0°, 15°, 25° and 40°
- 50" x 3/8" steel wire-braided high pressure hose with quick connects
- Professional-grade insulated trigger gun with safety lock-off
- 47" pressure insulated lance
Specifications
- Pressure: 3500 PSI
- Flow: 21 L/min
- Engine: Honda gx690
- Pump: General TS2021, Nickel-plated head. Plunger / Triplex
- Diesel tank capacity: 54.5 L
- Burner: 12V
- Burner Fuel Cons: 2.66 GPH
- BTU / HOUR: 390,000
- Dimensions L X W X H: 117 cm x 112 cm x 130 cm
- Weight: 422 Kg
At a glance
| Engine - Brand | Honda |
| Engine - Model | GX690 V Twin |
| Engine - HP | 24 |
| Engine - Start | Electric |
| Drive | Belt |
| Frame - Type | Skid |
Manuals and parts
