Description
Specifications
- Capacity (Diameter): 80mm
- Capacity (Depth): 110mm
- Capacity (Twist Drills): 25mm
- Spindle Taper: MT3
- Motor Power: 1500 Watt 240V Motor
- Input Power: 1600 Watt
- Speed: 2 speed heavy-duty gearbox 160/390rpm
- Weight: 18kg
- Magnetic Dead Lift: 11 000 N on 25mm steel plate
- Stroke: 190mm
- Height (Min./Max.): 476mm/666mm
Key features
- Lightweight for a large capacity machine only 18kg
- Rigid casting designed to withst and firm downward drillingforce prolonging the machine and tooling life
- New generation Italian made motor and heavy-duty 2 speedgearbox
- Semi-automatic gib adjustment enables simple fastcorrect and repeatable slide backlash settings without anyexpert knowledge or experience
- Magnetic Field Shape Control (MFSC) provides maximumholding power on thin materials
- Magnetic Power Adhesion Control (MPAC) detects theadhesive force of the electromagnetic base and protects both the machine and the operator from working on too thinworkpiece
- 2 Years Warranty
