Description
- Elastic tips: dimensionally stable even when twisted
- Distortion-tolerant, elastic precision tips
- Half-round, long, tapered jaws
- With cutting edges for soft, medium-hard and hard wire
- Cutting edges additionally induction-hardened, cutting edge hardness approx. 61 HRC
- Straight jaws
- Vanadium electric steel, forged, multi stage oil-hardened
For profess. users from the electr., motor vehicle and comm. vehicle industries
Pliers for gripping, aligning and installation work and for cutting
The forged and oil-hardened snipe nose side cutting pliers from Knipex are primarily used for gripping, aligning and installation work. The second function of these pliers lies in powerful cutting – a regularly occurring task during assembly work. Their cutting edges are shaped to produce a bite type cut. The cutting edges of the pliers are additionally induction hardened, so that the Knipex 26 11 200 is even suitable for cutting hard wire.
Inherently stable when twisted – particularly strong when cutting
The precision tips made of vanadium electric steel are elastic and stable when twisted. This allows the manual force deployed to be well measured – forcefully where necessary. The cutting edges are near the joint which is advantageous for the transmission of force. The high cutting capacities achieved of Ø 3.2 mm (medium-hard wire) and Ø 2.2 mm (hard wire) are impressive.
Poorly accessible areas can be reached easily with these pliers
The very long tips of the Knipex 26 11 200 make it possible to grip low-lying components that are hard to reach accurately and powerfully. Anyone who needs to attach or connect a hose onto a difficult to reach nozzle or a refrigerant pipe to the air conditioning evaporator will immediately appreciate the qualities of the snipe nose side cutting pliers.
Technical attributes
| Part No. | 26 11 200 |
|---|---|
| EAN | 4003773022824 |
| Pliers | black atramentized |
| Head | polished |
| Handles | with plastic coating |
| Weight | 170 g |
| Dimensions | 200 x 51 x 13 mm |
| Standard | DIN ISO 5745 |
| REACH compliant | does not contain SVHC |
| RoHS compliant | not applicable |
| Cutting capacities medium hard wire (diameter) | Ø 3.2 mm |
| Cutting capacities hard wire (diameter) | Ø 2.2 mm |
| Jaw thickness (joint) (T1) | 9.5 mm |
| Tips width (W4) | 3.0 mm |
| Tips thickness (T2) | 2.5 mm |
| Jaw length (L3) | 73.0 mm |
| Head width (W3) | 18 mm |
